The CGR-30c provides a color display in a 2 1/4″ standard aircraft mount. It incorporates one screen in a number of display formats.

TQC-23 Screen

Configuration Examples:

  • Any Function can be displayed in any location.
  • Functions can be displayed in Arcs, Strips, Digital Only, or as an Annunciator.
  • Data Recording.
  • Real-Time-Data-Out (RTDO) Port.
  • Upload Configuration Files and download Flight Data via the flying USB Port.
  • When interfaced with the BC-5 the CGR-30C can display data on almost any digital bus.
  • The TQC-23 receives and processes signals from almost any transducer, probe or sensor, or interface with the EDC-33.
  • Scaling and Color Ranges can be configured for every function.
  • FAA TSO’d.
  • Night Vision Compatible.
  • Contact Electronics International inc. and let us help you with a configuration that meets your requirements

Specifications (temporary placeholder – needs update)

Dimensions
3.25” x 3.25” x 4.45” Deep, 3 1/8” Flush Mount

Weight
1.1 Pounds (Instrument Only)

Power Requirements
7.5 to 30 Volts
Typical: 0.2 amps @ 12 Volts, 0.1 amps @ 24 Volts

Display
Active Matrix, Sunlight Readable

Backlight
Fully Dimmable for Night Flights

USB Port
Data Download and Software Updates

Internal Storage
Up to 1,500 most recent flights stored. All monitored functions are stored up to three times per second. Recorded flight data can be easily downloaded via USB port.

Certifications

  • FAA TSO’d to DO-160G
  • FAA DO-178 Level C
